Garage on a VPS: Lightweight Distributed S3-Compatible Storage for Multi-Server Setups
Garage is an open-source, lightweight distributed object storage system — S3-compatible, written in Rust, and designed to run on multiple small VPS instances forming a storage cluster. Unlike MinIO (excellent for single-server S3), Garage is specifically built for multi-server distributed storage: data is automatically sharded and replicated across nodes, surviving individual server failures. For teams with 2–5 VPS instances wanting S3-compatible distributed storage without running complex Ceph clusters.
Garage vs MinIO for Multi-Server Storage
- Garage: Designed for small clusters (3–10 nodes), geographic distribution, simple configuration, excellent data durability with replication
- MinIO: Excellent single-server S3, more complex distributed mode (MinIO Distributed), enterprise features
- Ceph: Extremely capable, extremely complex — appropriate for large clusters (10+ nodes)
- Choose Garage: 3–5 VPS nodes wanting simple, reliable distributed S3 without operational complexity
Architecture: 3-Node Cluster
<code"># Setup: 3 VPS nodes in different datacenters/zones # node1: 192.168.1.10 (Zone: us-east) # node2: 192.168.1.11 (Zone: us-west) # node3: 192.168.1.12 (Zone: eu-west) # # Replication: data written to 2 out of 3 zones # Reads: served from nearest available zone # Failures: cluster continues if 1 node is down
Step 1: Install Garage on Each Node
<code"># Run on ALL 3 nodes:
mkdir -p /opt/garage /var/lib/garage
# Download Garage binary
wget https://garagehq.deuxfleurs.fr/garage-v1.0.0-linux-x86_64 \
-O /usr/local/bin/garage
chmod +x /usr/local/bin/garage
garage --version
Step 2: Configure Garage (Each Node)
<code">sudo nano /etc/garage/garage.toml
<code"># Node 1 configuration (adjust node_id and rpc_public_addr per node) metadata_dir = "/var/lib/garage/meta" data_dir = "/var/lib/garage/data" [network_key] # Generate ONCE and use SAME key on all nodes: # openssl rand -base64 32 key = "YOUR_SHARED_NETWORK_KEY_BASE64" [rpc] # THIS node's public address (other nodes connect to this): public_addr = "192.168.1.10:3901" bind_addr = "0.0.0.0:3901" [s3_api] s3_region = "garage" api_bind_addr = "0.0.0.0:3900" root_domain = ".s3.yourdomain.com" [admin] api_bind_addr = "127.0.0.1:3903"
<code">sudo nano /etc/systemd/system/garage.service
<code">[Unit] Description=Garage S3 Storage After=network.target [Service] Type=simple ExecStart=/usr/local/bin/garage server --config /etc/garage/garage.toml Restart=on-failure [Install] WantedBy=multi-user.target
<code"># On ALL nodes: sudo systemctl enable garage sudo systemctl start garage
Step 3: Form the Cluster
<code"># Connect nodes to each other (run on node1):
garage node connect 192.168.1.11:3901 # Connect to node2
garage node connect 192.168.1.12:3901 # Connect to node3
# List all nodes:
garage node list
# Shows: node IDs, addresses, status
# Assign nodes to zones (for geographic distribution):
# FIRST: get each node's ID from the output above
NODE1_ID="abc123..."
NODE2_ID="def456..."
NODE3_ID="ghi789..."
garage layout assign \
"$NODE1_ID" --zone "us-east" --capacity 100 --tag "node1"
garage layout assign \
"$NODE2_ID" --zone "us-west" --capacity 100 --tag "node2"
garage layout assign \
"$NODE3_ID" --zone "eu-west" --capacity 100 --tag "node3"
# Preview the layout:
garage layout show
# Apply the layout:
garage layout apply --version 1
# Verify cluster health:
garage status
Step 4: Create Buckets and Keys
<code"># Create a bucket:
garage bucket create my-app-files
garage bucket create backup-data
# Create access keys:
garage key create app-backend
# Output: ACCESS_KEY_ID and SECRET_ACCESS_KEY
# Grant access:
garage bucket allow my-app-files \
--read --write --owner \
--key app-backend
# Create read-only key for CDN/download:
garage key create cdn-reader
garage bucket allow my-app-files --read --key cdn-reader
Step 5: Configure Replication
<code"># Garage replication options: # mode = "1": no replication (data on 1 node) # mode = "2": 2-copy replication (survives 1 node failure) # mode = "3": 3-copy replication (survives 2 node failures) # Configure in garage.toml: [garage] replication_mode = "2" # For 3 nodes, 2-copy is standard # After changing, apply layout again: garage layout apply --version 2
Step 6: Use with AWS SDK
<code">pip install boto3
<code">import boto3
from botocore.client import Config
# Connect to Garage (same as MinIO/S3)
s3 = boto3.client(
's3',
endpoint_url='https://s3.yourdomain.com', # or 'http://node1:3900'
aws_access_key_id='YOUR_ACCESS_KEY',
aws_secret_access_key='YOUR_SECRET_KEY',
region_name='garage',
config=Config(signature_version='s3v4'),
)
# All standard S3 operations work:
s3.upload_file('myfile.pdf', 'my-app-files', 'documents/myfile.pdf')
url = s3.generate_presigned_url('get_object',
Params={'Bucket': 'my-app-files', 'Key': 'documents/myfile.pdf'},
ExpiresIn=3600)
# List buckets
for bucket in s3.list_buckets()['Buckets']:
print(bucket['Name'])
Step 7: Nginx for S3 API (Public Endpoint)
<code">sudo nano /etc/nginx/sites-available/garage-s3
<code">server {
listen 443 ssl http2;
server_name s3.yourdomain.com *.s3.yourdomain.com;
ssl_certificate /etc/letsencrypt/live/s3.yourdomain.com/fullchain.pem;
ssl_certificate_key /etc/letsencrypt/live/s3.yourdomain.com/privkey.pem;
client_max_body_size 10000M;
proxy_read_timeout 600s;
proxy_request_buffering off;
location / {
proxy_pass http://127.0.0.1:3900;
proxy_set_header Host $http_host;
proxy_set_header X-Forwarded-For $remote_addr;
}
}
Getting Started
Each Garage node uses 50–100 MB RAM regardless of stored data volume. Three small 1 GB Ubuntu VPS at VPS.DO nodes form a reliable distributed storage cluster. The cluster survives one node failure and automatically rebalances when it comes back. For organizations with multiple VPS instances already running other services, Garage adds distributed object storage without dedicated storage hardware.
Conclusion
Garage provides distributed S3-compatible object storage designed for small VPS clusters — simpler than Ceph, more resilient than MinIO single-server. Data is automatically sharded and replicated across zones, surviving individual server failures. The S3 API compatibility means any existing S3 integration works with Garage unchanged. For teams with 3+ VPS instances wanting private, self-hosted distributed storage without cloud egress fees, Garage is the right-sized solution between MinIO’s simplicity and Ceph’s complexity.
